Xerox VersaLink B7025 Service Manual

April 2017
2-467
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
071-100, 071-105
Status Indicator RAPs
Launch Issue
071-100 Tray 1 Misfeed RAP
BSD-ON: BSD 7.7 Tray 1 Paper Stacking
BSD-ON: BSD 8.1 Tray 1 and Bypass Tray Paper Transportation
071-100 Paper does not actuate the tray 1 feed out sensor within the specified time after tray 1
feed start.
Initial Actions
• Check the condition of the paper in tray 1. Refer to GP 15 Paper and Media Size Specifi-
cations.
• Check that the tray 1 paper guides are set correctly.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the tray 1 feed roll, nudger roll and retard roll, PL 80.11 for foreign substances or
wear. Clean or install new components as necessary.
3. Check the registration roll and takeaway roll 1, PL 80.55 for foreign substances or wear.
Clean or install new components as necessary.
4. Enter dC330, code 071-105. Check the tray 1 pre feed sensor, PL 80.10 Item 22.
5. Enter dC330, code 071-002. Check the tray 1 feed/lift up motor, PL 80.10 Item 4.
6. Check the drive gears, PL 80.10 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new drive PWB, PL 1.10 Item 3.
071-105 Registration Sensor Jam (Tray 1) RAP
BSD-ON: BSD 7.7 Tray 1 Paper Stacking
BSD-ON: BSD 8.5 Registration
071-105 The registration sensor did not actuate within the specified time after the registration
clutch initialized during paper feed from tray 1.
Initial Actions
Check the condition of the paper in tray 1. Refer to GP 15 Paper and Media Size Specifications
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the tray 1 feed roll, nudger roll and retard roll, PL 80.11 for foreign substances or
wear. Clean or install new components as necessary.
3. Enter dC330, code 077-104. Check the registration sensor, PL 80.55 Item 4.
4. Enter dC330, code 077-002. Check the registration clutch, PL 80.55 Item 11.
5. Enter dC330, code 077-001. Check the take away clutch, PL 40.10 Item 5.
6. Enter dC330, code 071-002. Check the tray 1 feed/lift up motor, PL 80.10 Item 4.
7. Enter dC330, code 042-003. Check the main motor, PL 40.10 Item 1.
8. Check the drive assembly, PL 40.10 Item 7 for wear or damage.
9. If the fault persists, install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
