Xerox VersaLink B7025 Service Manual

April 2017
2-482
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
077-305, 077-308
Launch Issue
Status Indicator RAPs
077-305 TM Left Cover Open RAP
BSD-ON: BSD 1.9 Power Interlock Switching (2 of 3)
077-301 Tray module left cover was opened during run.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 9 How to Check a Switch
Perform the steps that follow:
1. Check the actuator on the tray module left cover for damage. If necessary, install a new
tray module left cover:
• (1TM), PL 70.16 Item 6.
• (3TM), PL 70.21 Item 6.
•(STM), PL 70.25 Item 2.
•(TTM), PL 70.70 Item 7.
2. Enter dC330, code 077-306. As necessary, perform the steps that follow:
• Check the 1TM left cover switch, PL 80.15 Item 3.
• Check the 3TM left cover switch, PL 80.30 Item 8.
• Check the STM left cover switch, PL 80.35 Item 4.
• Check the TTM left cover switch, PL 70.95 Item 18.
3. If the fault persists, install new components as necessary:
• 1TM PWB, PL 70.17 Item 5.
• 3TM PWB, PL 70.23 Item 5.
•STM PWB, PL 70.28 Item 4.
• TTM PWB, PL 70.90 Item 1.
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
077-308 L/H High Cover Open RAP
BSD-ON: BSD 10.5 Fused Paper Exit 2
077-308 L/H high cover was was opened during run.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 9 How to Check a Switch
Perform the steps that follow:
1. Check the actuator on the left hand transport assembly, PL 10.20 Item 2 for damage. If
necessary, install a new left hand transport assembly,
2. Enter dC330 code 077-302. Check the left hand high cover switch, PL 10.21 Item 3.
3. If the fault persists, install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
