Xerox VersaLink B7025 Service Manual

April 2017
2-462
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
061-361, 062-277
Launch Issue
Status Indicator RAPs
061-361 LPH Configuration RAP
BSD-ON: BSD 6.4 Laser Control
061-361 The model number of the installed LPH does not match. It may also be a memory
error in the LPH.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. Check that a valid LPH is installed.
3. If the fault persists, install new components as necessary:
• Print head assembly, PL 60.35 Item 1.
• ESS PWB, PL 3.10 Item 6.
062-277 DADF Communication Fail RAP
BSD-ON: BSD 3.5 PWB Communications (ESS PWB to DADF)
062-277 Communications cannot be established between the ESS PWB and the DADF PWB.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. Check the connections and wiring between the ESS PWB ( P/J750) and the DADF PWB (
P/J751) for an open circuit, short circuit or poor contact.
3. If the fault persists, install new components as necessary:
• DADF PWB, PL 5.10 Item 11.
• ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
