Xerox VersaLink B7025 Service Manual

April 2017
2-448
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
042-406, 043-344
Launch Issue
Status Indicator RAPs
042-406 Deodorant Filter Near Life End RAP
042-406 The Deodorant Filter must be replaced.
Procedure
For information only, no service action necessary.
043-344 Marking Fan Fail RAP
BSD-ON: BSD 9.7 Marking Fan Control
043-344 Marking fan fault.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 6 How to Check a Motor.
Enter dC330 code 042-052 to run the marking fan. The marking fan runs.
YN
Check the +24V power supply to the marking fan. The power supply is good.
YN
Check the power supply circuit to the marking fan.
Check the items that follow:
• The connection between the marking fan ( P/J209) and the drive PWB ( P/J410) for
open circuit, short circuit or poor contact.
• Load towards the marking fan.
Install new components as necessary:
• Marking fan PL 40.15 Item 8.
• Drive PWB, PL 1.10 Item 3.
The fault may be intermittent. Check the connection between the marking fan ( P/J209) and the
drive PWB ( P/J413) for open circuit, short circuit or poor contact.
Install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
