Xerox VersaLink B7025 Service Manual

April 2017
2-38
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-125, 005-145, 005-131, 005-132
Launch Issue
Status Indicator RAPs
005-125, 005-145 DADF Registration Sensor Off Jam RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-125 After the DADF pre registration sensor turned off at scan operation, the DADF regis-
tration sensor did not turn off within the specified time.
005-145 After the DADF pre registration sensor turned off at invert operation, the DADF regis-
tration sensor did not turn off within the specified time.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the registration roll, out roll and exit roll for foreign substances or
wear. Clean or install new components as necessary, PL 5.50.
3. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-131, 005-132 DADF Invert Sensor On Jam During
Inverting RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-131 After the DADF registration sensor turned on at invert operation, the DADF invert sen-
sor did not turn on within the specified time.
005-132 DADF invert sensor will not turn on after DADF registration sensor on in simplex.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the out roll for foreign substances or wear. Clean or install new com-
ponents as necessary, PL 5.50.
3. Enter dC330, code 005-211. Check the DADF invert sensor, PL 5.50 Item 8.
4. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
