Xerox VersaLink B7025 Service Manual

April 2017
2-63
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-161A, 012-210
Status Indicator RAPs
Launch Issue
YN
Install a new eject home sensor, PL 12.26 Item 9.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-054 and 012-056 alternately. The eject motor runs.
YN
Check the connections of P/J8706 and P/J8741. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8706 and P/J8741. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8706 pin 13 (+) and ground (-), and
between P/J8706 pin 15 (+) and ground (-).
The voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams.
Check the eject motor drive mechanism for deformed parts, broken parts, and/or belt
damage
The drive mechanism is good.
YN
Repair defects or damage to the drive mechanism. Install new components as nec-
essary, PL 12.25.
Install a new eject motor, PL 12.25 Item 15. If the fault persists, install a new finisher
PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-210 NVM Fail Entry RAP
012-210 An error is detected at NVM access.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-210A NVM Fail RAP.
• Office finisher LX installed, 012-210B Stacker Tray Fail RAP.
A

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
