Xerox VersaLink B7025 Service Manual

April 2017
2-539
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
117-340, 117-342, 117-343
Status Indicator RAPs
Launch Issue
117-340, 117-342 Other HDD Fail RAP
117-340 A hard disk that was formatted by another machine was detected.
117-342 Storage device incorrect-exchanged fault.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Install a new hard disk, PL 3.10 Item 2.
2. If the fault persists:
a. Switch off, then switch on the machine, GP 10.
b. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL
3.10 Item 6 are securely connected. Ensure all surface mounted modules on both
PWBs are securely connected.
c. Reload the software, GP 4.
d. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
117-343 Log Sending Parameter Fail RAP
117-343 An incorrect setting of the log transfer function was detected:
1. When the image log function is disabled and the auto transfer function is enabled, transfer
in job units is set.
2. When the job log auto transfer function is disabled (no hard disk), the auto transfer func-
tion of the log is set to enabled.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Have the customer change the settings of the log transfer function:
• For detection condition 1, change the operation method for Log Auto Transfer to
anything other than Transfer in Job Units.
• For detection condition 2, check whether a hard disk is installed or change the Auto
Transfer function of the log to disable it.
2. Reload the software, GP 4.
3. Perform the OF2 Special Boot Modes RAP.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
