Xerox VersaLink B7025 Service Manual

April 2017
2-565
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
124-345, 124-346, 348, 354
Status Indicator RAPs
Launch Issue
124-345 Billing Meter Type Restoration Fail RAP
124-345 Billing meter type fail (one mismatches the others but cannot be automatically
repaired.)
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC131. Compare NVM values 720-002 and 720-062. Both values are different.
YN
Install a new drive PWB, PL 1.10 Item 3.
Install a new ESS PWB, PL 3.10 Item 6.
124-346, 348, 354 Information Mismatch RAP
124-346 Billing count type fail (all the three are different from each other).
124-348 Modal break point fail (all the three are different from each other).
124-354 Territory info fail (contents corrupted, the controller pwb was replaced).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. If the fault persists, install a new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• Drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
