Xerox VersaLink B7025 Service Manual

April 2017
2-465
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
062-362, 062-371, 380, 386, 393
Status Indicator RAPs
Launch Issue
062-362 X Hard Fail RAP
062-362 Hard modification of authentication machine was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
062-371, 380, 386, 393 Lamp Illumination Fail RAP
BSD-ON: BSD 6.3 Document Illumination and Image Input
062-371 Insufficient light from Lamp detected in CCD (during white gradation correction/agc
before scan starts)
062-380 Insufficient lamp brightness was detected when performing AGC.
062-386 A CCD output error was detected when performing AOC.
062-393 Write failure to the Shading Memory has occurred.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform ADJ 60.5 Optics Cleaning Procedure.
Procedure
1. Check the ribbon cable between the ESS PWB and the lamp assembly. If necessary,
install a new FFC LED cable assembly, PL 60.20 Item 10.
2. If the fault persists, install new components as necessary:
• Lamp assembly, PL 60.20 Item 9.
• ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
