Xerox VersaLink B7025 Service Manual

April 2017
2-308
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-370, 024-371 to 024-373, 024-375
Launch Issue
Status Indicator RAPs
024-370 Marker Code Detection Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
024-370 Marker code detection error. During enlarge, when the file was enlarged only by the
specified size, the end code (FF02) cannot be found in the compressed data.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Change the Print mode (Normal/High Quality/High Resolution). Inform the customer of
any print mode setting changes.
3. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
4. Remove, then re-install the SD card, PL 3.10 Item 11.
5. Reload the software, GP 4.
6. Perform the OF2 Special Boot Modes RAP.
7. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
•SD card, PL 3.10 Item 11.
024-371 to 024-373, 024-375 IOT-ESS Communication Fail 2
RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
024-371 Communication between the ESS and IOT has not been established.
024-372 Sending error detected by the controller (incorrect parameter instruction).
024-373 DLL communication failure recovery error detected by the controller.
024-375 DLL receiving error detected by the controller (incorrect parameter instruction).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
5. If the fault persists, install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
