April 2017
2-452
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
047-213, 047-216, 047-217
Launch Issue
Status Indicator RAPs
047-213, 047-216 Finisher Communication RAP
BSD-ON: BSD 1.7 Option DC Power Distribution
BSD-ON: BSD 3.6 PWB Communications (ESS PWB/Drive PWB to Finisher)
047-213 The connected finisher is of an incorrect type.
047-216 Reply from the finisher was determined as a communication error.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the connection between the drive PWB ( P/J590 and P/J591) and the finisher
PWB (J401) for open circuit, short circuit or poor contact.
3. Install new components as necessary:
• (Integrated office finisher) finisher PWB, PL 12.14 Item 1.
• (Office finisher LX) finisher PWB, PL 13.45 Item 2.
•Drive PWB, PL 1.10 Item 3.
047-217 HCF Communication RAP
BSD-ON: BSD 3.15 PWB Communications (ESS to HCF)
047-217 Reply from the HCF was determined as a communication error.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the connection between the drive PWB, PL 1.10 Item 3 and the HCF PWB, PL
70.60 Item 9 for open circuit, short circuit or poor contact.
3. Install new components as necessary:
• HCF PWB, PL 70.60 Item 9.
• Drive PWB, PL 1.10 Item 3.
