April 2017
2-114
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-311, 315, 319, 016-312, 313, 314
Launch Issue
Status Indicator RAPs
016-311, 315, 319 Scanner Not Detected RAP
016-311 The system detected that the scanner was not installed.
016-315 An error in the I/F between the scanner and the main processor was detected.
016-319 An error in the I/F between the scanner and the main unit was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
016-312, 313, 314 SW Option Fail (Hybrid WaterMark) RAP
016-312 When the SW optional function is being enabled, the system detected that the hybrid
watermark detection H/W is not installed.
016-313 The hybrid watermark detection H/W was detected but the SW option (secure water-
mark kit) was not enabled.
016-314 The board for detecting the back (side 2) of a document is not installed. Therefore
(paper security) is unavailable.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
