Xerox VersaLink B7025 Service Manual

April 2017
2-90
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-260, 012-282
Launch Issue
Status Indicator RAPs
012-260, 012-282 Eject Clamp Home Sensor Fail RAP
BSD-ON: BSD 13.13 Office Finisher LX Eject Control (1 of 2)
012-260 After the eject clamp started ascending, the eject clamp home sensor did not turn on
within 500ms.
012-282 After the eject clamp started descending, the eject clamp home sensor did not turn off
within 200ms.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Manually operate the eject mechanism. Check for binding, a dirty sensor, or damage.
• Check the actuator for the eject clamp home sensor, PL 13.27 Item 16 for damage
Procedure
Enter dC330 code 012-250. Actuate the eject clamp home sensor. The display changes.
YN
Check the wiring between J8870 pin 2 on the eject clamp home sensor and P/J8988 pin
8 on the finisher PWB for an open or short circuit, or loose or damaged connectors.
The
wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 9 and 7 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 8 on the finisher PWB and ground. Actuate
the eject clamp home sensor.
The voltage changes.
YN
Install a new eject clamp home sensor, PL 13.27 Item 16.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 code 012-052 and 012-053 alternately. The eject motor runs.
YN
Check the wiring between P/J8878 pins 1 to 6 on the eject motor and P/J8983 pins 5 to
8 on the finisher PWB for an open or short circuit, or loose or damaged connectors.
The
wiring is good.
YN
Reconnect or repair as necessary.
Measure the resistance of the eject motor between each pin of P/J8878 pins 1, 3, 4 and
6.
The resistance is approximately 2 Ohm.
YN
Install a new eject motor, PL 13.27 Item 4.
Install a new finisher PWB, PL 13.45 Item 2. If the problem persists, install a new eject
motor, PL PL 13.27 Item 4.
Check for an intermittent circuit or intermittent mechanical problem. If the check is good, install
a new finisher PWB, PL 13.45 Item 2.
A
A
B
B
