Xerox VersaLink B7025 Service Manual

April 2017
2-573
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
127-310 to 127-315, 342, 127-320
Status Indicator RAPs
Launch Issue
127-310 to 127-315, 342 ESS Error RAP
127-310 A fatal error occurred in ESR task.
127-311 Fatal error related to ExtPRTc.
127-312 DFE detected a video link error.
127-313 ESS detected a video link error.
127-314 ESS detected a video link error.
127-315 A problem has occurred with software processing, causing the processing to stop.
127-342 A response such as system function recall error was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
127-320 DFE Critical Fail RAP
127-320 An error occurred in the connection to the DFE. Or the DFE needs to treat the device
as SystemFail.
Procedure
Advise the customer to:
1. To take the corrective actions based on the fault code displayed in the DFE monitor, then
reboot the system.
2. Check the device settings.
3. Check the connection to the DFE.
4. Check the DFE hardware.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
