Xerox VersaLink B7025 Service Manual

April 2017
2-445
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
041-340, 041-341, 041-371
Status Indicator RAPs
Launch Issue
041-340, 041-341 Drive PWB NVM (EEPROM) Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
041-340 NVM (EEPROM) data abnormality.
041-341 NVM (EEPROM) access error.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Fault code 041-340 Only. Enter dC131. Check that the NVM values that follow are set to 0:
• 740-016 Range Over Chain No
• 740-017 Range Over Link No
• 740-018 Range Over Chain Link
• 740-019 Range Over Value
• 740-020 Write in Progress Range Over Chain No
• 740-021 Write in Progress Range Over Link No
Procedure
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
3. dC301 NVM Initialization.
4. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
041-371 Productivity Not Set RAP
041-371 Productivity not set.
Procedure
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. If the fault persists, perform dC132.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
