April 2017
2-44
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-305, 005-500
Launch Issue
Status Indicator RAPs
005-305 DADF Feeder Cover Interlock Open RAP
BSD-ON: BSD 5.1 DADF Interlock and Document Setting
005-305 The DADF feeder cover was opened during DADF operation.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check the actuator on the upper feeder assembly, PL 5.10 Item 10. If the actuator is dam-
aged, install a new upper feeder assembly, PL 5.10 Item 10.
2. Enter dC330, code 005-212. Check the CVT feeder cover sensor, PL 5.10 Item 14.
3. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-500 Write to DADF-ROM Error RAP
005-500 An error has occurred during the process of writing data to the DADF-ROM.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Reload the software, GP 4
2. Install a new DADF PWB, PL 5.10 Item 11.
