April 2017
2-457
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
058-310 to 058-321
Status Indicator RAPs
Launch Issue
058-310 to 058-321 Fuser Checkout RAP
BSD-ON: BSD 10.1 Fusing Heat Control (1 of 2)
BSD-ON: BSD 10.2 Fusing Heat Control (2 of 2)
058-310 At warm up, the heat roll NC sensor temperature has exceeded the check tempera-
ture.
058-311 At warm up, the heat roll thermistor temperature has exceeded the check tempera-
ture.
058-318 After inspection start, the side temperature rises from the measurement start temper-
ature to the target temperature sooner than the specified time.
058-319 The heater assessment time has arrived, the center temperature or side temperature
is the setting value or less.
058-320 The side temperature does not rise to the measurement start temperature within the
specified time from the inspection start.
058-321 The side temperature does not rise from the measurement start temperature to the
target temperature within the specified time from the inspection start.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Remove the fuser. Check whether foreign substances or paper is wound around the heat
roll.
Procedure
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. (Fault code 058-310 only) Check the heat roll NC sensor for correct installation and
loose connections.
3. (Fault code 058-311 only) Check the heat roll thermistor for correct installation and loose
connections.
4. (Fault code 058-319 only) Check the heater for a wiring error.
5. (Fault code 058-320 only) Check the main heater rod for open circuit or poor contact.
6. (Fault code 058-321 only) Check the sub heater rod for open circuit or poor contact.
7. Ensure that the fuser is installed correctly and is the correct voltage for the region.
8. Check the drawer connector between the fuser and the main unit ( DP612) for damage.
9. Check the connections and wiring between the fuser ( DP612) and the LVPS ( P2) for an
open circuit, short circuit or poor contact.
10. Check the connections and wiring between the heat roll NC sensor ( P/J124) and the
drive PWB ( P/J416) for open circuit, short circuit or poor contact.
11. If the fault persists, install new components as necessary:
•Fuser, PL 10.05 Item 2.
• LVPS, PL 1.10 Item 8.
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
To Next Page
