Xerox VersaLink B7025 Service Manual

April 2017
2-46
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-913, 005-915
Launch Issue
Status Indicator RAPs
005-913 DADF Invert Sensor Static Jam RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-913 DADF invert sensor detected paper when powering on, closing the feeder cover or
closing the DADF.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Enter dC330, code 005-211. Check the DADF invert sensor, PL 5.50 Item 8.
2. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-915 DADF APS Sensor 1 Static Jam RAP
BSD-ON: BSD 5.5 Document Feeding (2 of 2)
005-915 DADF APS sensor 1 detected paper when powering on, closing the feeder cover or
closing the DADF.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Enter dC330, code 005-218. Check the DADF APS sensor 1, PL 5.50 Item 8.
2. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
