Xerox VersaLink B7025 Service Manual

April 2017
8-93
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Product Technical Overview
Launch Issue
Hole Punch Box
The punch box is located beneath the hole punch assembly and collects the discarded chads.
This will need to be emptied periodically. Refer to Figure 48.
Figure 48 Hole punch box
Customer Replaceable Units
Refer to Figure 49. The only customer replaceable units (CRUs) for the LX finisher are:
• The 5,000 stitch staple cartridge and
• The two staple cassettes for the booklet maker. Each of the staple cassettes holds 2,000
staples.
Figure 49 Customer replaceable units
Punch box

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
