Xerox VersaLink B7025 Service Manual

April 2017
2-321
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-928A, 024-928B
Status Indicator RAPs
Launch Issue
024-928A Scratch Sheet Compile RAP
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 024-928 Scratch Sheet Compile
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the finisher top cover, PL 12.05 Item 10 can be opened, then closed.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the specification of the paper, refer to GP 15 Paper and Media Size Specifications.
The paper is within specification.
YN
Load new paper that is in specification.
Check the condition of the paper. The paper is in good condition.
YN
Load new paper that is in specification.
Check the fault history, dC122 for a fault code. Another fault code is displayed.
YN
If the fault persists, install a new finisher PWB, PL 12.14 Item 1.
Perform the relevant RAP.
024-928B Scratch Sheet Compile RAP
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 024-928 Scratch Sheet Compile
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Ensure that the eject cover, PL 13.25 Item 1 is closed.
Procedure
Check the specification of the paper, refer to GP 15 Paper and Media Size Specifications.
The paper is within specification.
YN
Load new paper that is in specification.
Check the condition of the paper. The paper is in good condition.
YN
Load new paper that is in specification.
Check all connectors on the finisher PWB. The connectors are connected correctly.
YN
Connect the connectors.
Switch off, then switch on the machine, GP 10. Open, then close the eject cover. If the fault
persists, install a new finisher PWB, PL 13.45 Item 2.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
