Xerox VersaLink B7025 Service Manual

April 2017
2-506
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
116-321, 322, 323, 328, 329, 338, 116-324
Launch Issue
Status Indicator RAPs
116-321, 322, 323, 328, 329, 338 Software Error RAP
116-321 Due to an error in software processing, subsequent processes cannot be performed.
116-322 Due to an error in software processing, subsequent processes cannot be performed.
116-323 During a read/write check at power on, OS/DD detects an error with the ESS-NVRAM
board.
116-328 A failure was detected in the level 2 cache built in the CPU.
116-329 A system call error related to the serial I/F was detected.
116-338 Overall JBA fatal error. Due to an error in software processing, subsequent processes
cannot be performed.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
116-324 Exception Fail RAP
116-324 A fatal software exception error has occurred in the controller PWB CPU.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Check the wiring between the ESS PWB, PL 3.10 Item 6 and the hard disk.
5. Initialise the hard disk. Refer to dC355 Hard Disk Diagnostics.
6. Initialize the Sys - System NVM, refer to dC301.
7. Install a new hard disk, PL 3.10 Item 2.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
