Xerox VersaLink B7025 Service Manual

April 2017
2-509
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
116-341, 342, 393, 394, 116-343, 346, 357, 359
Status Indicator RAPs
Launch Issue
116-341, 342, 393, 394 ROM Version Incorrect RAP
116-341 Versions of the multiple ROM DIMMs installed are incorrect.
116-342 Fatal error related to the SNMP agent.
116-393 AAA manager fatal error.
116-394 Abnormal authentication mode and accounting mode settings detected during AAA
manager boot sequence.
Procedure
Reload the software, GP 4.
116-343, 346, 357, 359 Main PWB Error RAP
116-343 An error was detected in the IC in the ESS PWB.
116-346 A response such as system function recall error was detected.
116-357 PS Fatal System Error
116-359 Fatal error in PLW.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
