Xerox VersaLink B7025 Service Manual

April 2017
2-511
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
116-355, 363, 367, 370, 373, 376, 116-364, 365, 366,
Status Indicator RAPs
Launch Issue
116-355, 363, 367, 370, 373, 376 Fatal Error RAP
116-355 Fatal error related to the SNMP Agent.
116-363 BMLinkS/print service software failure.
116-367 Overall fatal error of Parallel.
116-370 Fatal error of XJCL.
116-373 Fatal error related to dynamic DNS.
116-376 Port 9100 software fail.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Advise the customer to check that the TCP/IP ports are correctly configured.
2. Switch off, then switch on the machine, GP 10.
3. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
4. Reload the software, GP 4.
5. Perform the 016A Scan to Network Error Entry RAP.
6. Perform the OF2 Special Boot Modes RAP.
116-364, 365, 366, 368, 371, 372, 375, 377 Timer Fail RAP
116-364 An error in the timer was detected.
116-365 Fatal error of the SPL.
116-366 Print utility operational failure, report generator operational failure.
116-368 Fatal error of DumpPrint.
116-371 PCL decomposer software failure.
116-372 Fatal error of P-formatter.
116-375 A response such as system function recall error was detected.
116-377 Video DMA failure was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
