Xerox VersaLink B7025 Service Manual

April 2017
4-26
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
REP 5.1
Launch Issue
Repairs and Adjustments
3. If a new DADF is installed perform the steps that follow:
a. Enter dC135 HFSI Counter. Reset the HFSI counters that follow:
• Chain-Link: 955-806
• Chain-Link: 955-807
• Chain-Link: 955-808
• Chain-Link: 955-810
• Chain-Link: 955-812
• Chain-Link: 955-826
• Chain-Link: 955-828
CAUTION
Take care when removing and reinstalling the SEEPROM. The pins are easily damaged.
b. Remove the SEEPROM (1) from the old DADF PWB, then install it onto the new
DADF PWB, Figure 4.
Figure 4 SEEPROM
CAUTION
If the original SEEPROM cannot be reused, the feed count, jam count and HFSI count will
be lost.
c. If the SEEPROM is damaged during removal and cannot be reused, enter dC131
NVM read/Write. Enter the DADF NVM settings listed below according to the NVM
Setting List that was supplied with the machine:
• 711-140
• 711-141
• 711-142
• 711-143
• 711-144
• 711-270
• 711-271
• 711-272
• 711-273
• 711-274
• 711-275
NOTE: The list is located in tray 1, beneath the RAI cover, PL 70.05 Item 10.
d. Check the machines current software level against the software level recorded prior
to installation of the new DADF. If necessary, reload the software, GP 4.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
