Xerox WorkCentre 3615

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-107
073-101 -
<IOT Path 3 SNS On Jam>
Cause:
The Tray 3 Path Sensor did not turn
ON within the specified time after the
Tray 4 Path Sensor turned ON.
FIP 1. 277
073-211
Tray3 Error 073-211
Power Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
Code:xxxxxxxxh
<Feeder 3 Error>
Cause:
IOT Option Feeder3 Failure.
FIP 1. 280
074-100 -
<IOT Tray 4 Misfeed Jam>
Cause:
After the Tray 4 Feed Clutch turned
ON, the Tray 4 Path Sensor did not
turn ON within the specified time.
FIP 1. 276
074-211
Tray4 Error 074-211
Power Off/On the Printer.
Contact customer support if this
failure is repeated.
<Feeder 4 Error>
Cause:
IOT Option Feeder4 Failure.
FIP 1. 280
075-100 -
<MSI Misfeed Jam>
Cause:
After the MSI Feed Solenoid turned
ON, the Regi. Sensor did not turn ON
within the specified time.
FIP 1. 281
077-101 -
<VSYNC ON Jam>
Cause:
Detect VSYNC ON Jam.
FIP 1. 282
077-104 -
<Regi. Off Jam>
Cause:
The Regi Sensor does not turn OFF
within the specified time after the Regi
Clutch turned On.
FIP 1. 283
077-106 -
<Exit On Jam>
Cause:
The Exit Sensor does not turn ON
within the specified time after the Regi
Clutch turned On.
FIP 1. 284
Status
Code
(3615)
LCD Display Name/Description of Error FIP
