Xerox WorkCentre 3615

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-108
077-107 -
<Duplex Regi On Jam>
Cause:
After the Invert Clutch turned ON, the
Regi. Sensor did not turn ON within the
specified time.
FIP 1. 284
077-108 -
<Exit Off early Jam>
Cause:
After the Exit Sensor turned ON, the
Exit Sensor turned OFF before the
specified time.
FIP 1. 284
077-109 -
<Exit Off Jam>
Cause:
After the Regi. Sensor turned OFF, the
Exit Sensor did not turn OFF within the
specified time.
FIP 1. 284
077-215
Duplex Unit Error
Reseat Duplex Unit and Power
Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
<IOT Duplexer Error>
Cause:
Duplex Unit Configuration error is
detected.
FIP 1. 285
077-217
Duplexer Error
Power Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
<Duplex Miss Configuration>
Cause:
Duplex Unit Configuration error is
detected.
FIP 1. 285
077-300
Front Cover Open
Close Front Cover.
<IOT Cover Front Open>
Cause:
Beep sounds after Front Cover remains
open for 3 minutes.
FIP 1. 286
077-304
Rear Door Open
Close Rear Door.
<IOT Cover Rear Open>
Cause:
The Rear Cover is open.
FIP 1. 287
077-312
Tray Configuration Error
Power Off/On the Printer.
If this failure occurs again,
please contact customer sup-
port.
Code:xxxxxxxxh
<Tray Configure Error>
Cause:
Tray configuration error was detected.
(including all of the wrong configura-
tions)
FIP 1. 288
Status
Code
(3615)
LCD Display Name/Description of Error FIP
