Page #90 background imageLoading...
Page #90 background image
Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-32
041-340
MCU NVRAM Error
Power Off/On
Error 041-340
Power Off/On
<IOT NVRAM Error>
Cause:
The operation error of NVM (read/write check
error etc.) is detected.
FIP 1. 252
041-347
MCU Int. Error
Power Off/On
Error 041-347
Power Off/On
<IOT I/F Failure>
Cause:
MCU Internal Error (I/F part).
FIP 1. 253
042-313
Fan Motor Error
Power Off/On
Error 042-313
Power Off/On
<LVPS Fan Motor Failure>
Cause:
MCU detects an error upon receiving error signal
from the LVPS Fan.
FIP 1. 254
042-330
IOT Start Error
Power Off/On
Error 042-330
Power Off/On
<Rear Fan Failure>
Cause:
MCU detects an error upon receiving error signal
from the Rear Fan.
FIP 1. 255
042-700
Printer Error
Power Off/On
Error 042-700
Power Off/On
<IOT Over Heat Stop>
Cause:
The temp. Sensor sensed high temperature.
FIP 1. 256
050-130
Paper Jam
Open Rear Door
and remove
jammed paper
<IOT Remain Zone Fusing Jam>
Cause:
When Dynamic Jam (cause) was detected:
077-104 Regi Off Jam
077-106 Exit On Jam
077-108 Exit Off Early Jam
077-109 Exit Off Jam
When Static Jam (collateral) was detected:
•Exit Sensor On
FIP 1. 257
050-131
Paper Jam
Open Rear Door
and remove
jammed paper
<IOT Remain Zone Duplex Jam>
Cause:
When Dynamic Jam (cause) was detected:
077-107 Duplex Regi On Jam
FIP 1. 258
Status
Code
(3610)
LCD Message Name/Description of Error FIP
