z Touch the IBP sites/ Channels tab (H).
The assignment of measuring points to IBP chan-
nels and connection positions is determined.
Each measuring point can be assigned only once!
If a measuring point already assigned is then as-
signed to a different channel, the previous channel
loses that measuring point and is "de-designated".
Calibration
z Touch the Cal. tab (I).
Calibration of individual catheter positions
J IBP meas. site: (ART, LV, PA, RV, CVP, RA,
LA, ICP, GP1, GP2),
K Zero individual blood pressure (only acti-
vated when a pressure gauge is connected)
L Calibration factor (only activated when a pres-
sure gauge is connected)
CPP measurement
CPP = ART
M–ICP
The CPP parameter is created and displayed (in
the lower parameter box of ICP), if both ICP and
ART are being monitored simultaneously and are
delivering valid measured values. If any of the
measured values are invalid or the measuring
points have not been configured, CPP is invalid as
well.
