MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
2-58 Freescale Semiconductor
Table 2-3. MPC5553 Power/Ground Segmentation
Power
Segment
Voltage
1
I/O Pins Powered by Segment
V
DDEH1
3.3–5.0 V TCRCLKA_IRQ[7]_GPIO[113], ETPUA[0:3]_ETPUA[12:15]_GPIO[114:117],
ETPUA[4:7]_ETPUA[16:19]_GPIO[118:121],
ETPUA[8:11]_ETPUA[20:23]_GPIO[122:125], ETPUA[12]_PCSB[1]_GPIO[126],
ETPUA[14]_PCSB[4]_GPIO[128], ETPUA[15]_PCSB[5]_GPIO[129],
ETPUA[16]_PCSD[1]_GPIO[130], ETPUA[17]_PCSD[2]_GPIO[131],
ETPUA[18]_PCSD[3]_GPIO[132], ETPUA[19]_PCSD[4]_GPIO[133],
ETPUA[20:27]_IRQ
[8:15]_GPIO[134:141],
ETPUA[28:31]_PCSC[1:4]_GPIO[142:145]
V
DDEH4
3.3–5.0 V CNTXA_GPIO[83], CNRXA_GPIO[84], PCSC[4]_ GPIO[86], PCSC[3]_GPIO[85],
EMIOS[0:9]_ETPUA[0:9]_GPIO[179:188], EMIOS[10:11]_GPIO[189:190],
EMIOS[12]_SOUTC_GPIO[191], EMIOS[13]_SOUTD_GPIO[192],
EMIOS[14:15]_IRQ
[0:1]_GPIO[193:194],
EMIOS[16:23]_ETPUB[0:7]_GPIO[195:202]
V
DDEH6
3.3–5.0 V CNTXC_PCSD[3]_GPIO[87], CNRXC_PCSD[4]_GPIO[88], PCSC[1]_GPIO[93],
PCSC[2]_GPIO[94], PCSC[5]_GPIO[95], PCSD[2]_GPIO[96], PCSB[2]_GPIO[97],
SCKD_GPIO[98], SOUTD_GPIO[100], PCSB[3]_GPIO[101],
PCSB[3]_SINC_GPIO[108], PCSB[4]_SCKC_GPIO[109],
PCSB[5]_PCSC[0]_GPIO[110], RESET
, RSTOUT, PLLCFG[0]_IRQ[4]_GPIO[208],
PLLCFG[1]_IRQ[5]_SOUTD_GPIO[209], RSTCFG_GPIO[210],
BOOTCFG[0]_IRQ
[2]_GPIO[211], BOOTCFG[1]_IRQ[3]_GPIO[212],
WKPCFG_GPIO[213], EMIOS[14:15]_GPIO[203:204]
V
DDEH8
3.3–5.0 V GPIO[205], ETRIG[0:1]_GPIO[111:112]
V
DDEH9
3.3–5.0 V AN[12]_MA[0]_SDS, AN[13]_MA[1]_SDO, AN[14]_MA[2]_SDI, AN[15]_FCK
V
DDEH10
3.3–5.0 V
SCKB_PCSC[1]_GPIO[102], SINB_PCSC[2]_GPIO[103],
SOUTB_PCSC[5]_GPIO[104], PCSB[0]_PCSD[2]_GPIO[105],
PCSB[1]_PCSD[0]_GPIO[106], PCSB[2]_SOUTC_GPIO[107]
V
DDE2
2
1.8–3.3 V CS[0]_ADDR[8]_GPIO[0], CS[1:3]_ADDR[9:11]_GPIO[1:3],
ADDR[8:11]_CAL_ADDR[27:30]_GPIO[4:7], ADDR[8:31]_GPIO[4:27],
RD_WR
_GPIO[62], BDIP_GPIO[63], WE/BE[0:1]_GPIO[64:65],
WE/BE[2:3]_CAL_WE/BE[0:1]_GPIO[66:67], TS_GPIO[69], TA_GPIO[70],
TEA_CAL_CS[0]_GPIO[71]
