MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor A-5
Pad configuration register 21 (ADDR25) SIU_PCR21 16-bits Base + 0x006A
Pad configuration register 22 (ADDR26) SIU_PCR22 16-bits Base + 0x006C
Pad configuration register 23 (ADDR27) SIU_PCR23 16-bits Base + 0x006E
Pad configuration register 24 (ADDR28) SIU_PCR24 16-bits Base + 0x0070
Pad configuration register 25 (ADDR29) SIU_PCR25 16-bits Base + 0x0072
Pad configuration register 26 (ADDR30) SIU_PCR26 16-bits Base + 0x0074
Pad configuration register 27 (ADDR31) SIU_PCR27 16-bits Base + 0x0076
Pad configuration register 28 (DATA0) SIU_PCR28 16-bits Base + 0x0078
Pad configuration register 29 (DATA1) SIU_PCR29 16-bits Base + 0x007A
Pad configuration register 30 (DATA2) SIU_PCR30 16-bits Base + 0x007C
Pad configuration register 31 (DATA3) SIU_PCR31 16-bits Base + 0x007E
Pad configuration register 32 (DATA4) SIU_PCR32 16-bits Base + 0x0080
Pad configuration register 33 (DATA5) SIU_PCR33 16-bits Base + 0x0082
Pad configuration register 34 (DATA6) SIU_PCR34 16-bits Base + 0x0084
Pad configuration register 35 (DATA7) SIU_PCR35 16-bits Base + 0x0086
Pad configuration register 36 (DATA8) SIU_PCR36 16-bits Base + 0x0088
Pad configuration register 37 (DATA9) SIU_PCR37 16-bits Base + 0x008A
Pad configuration register 38 (DATA10) SIU_PCR38 16-bits Base + 0x008C
Pad configuration register 39 (DATA11) SIU_PCR39 16-bits Base + 0x008E
Pad configuration register 40 (DATA12) SIU_PCR40 16-bits Base + 0x0090
Pad configuration register 41 (DATA13) SIU_PCR41 16-bits Base + 0x0092
Pad configuration register 42 (DATA14) SIU_PCR42 16-bits Base + 0x0094
Pad configuration register 43 (DATA15) SIU_PCR43 16-bits Base + 0x0096
Pad configuration register 44 (DATA16) SIU_PCR44 16-bits Base + 0x0098
Pad configuration register 45 (DATA17) SIU_PCR45 16-bits Base + 0x009A
Pad configuration register 46 (DATA18) SIU_PCR46 16-bits Base + 0x009C
Pad configuration register 47 (DATA19) SIU_PCR47 16-bits Base + 0x009E
Pad configuration register 48 (DATA20) SIU_PCR48 16-bits Base + 0x00A0
Pad configuration register 49 (DATA21) SIU_PCR49 16-bits Base + 0x00A2
Pad configuration register 50 (DATA22) SIU_PCR50 16-bits Base + 0x00A4
Pad configuration register 51 (DATA23) SIU_PCR51 16-bits Base + 0x00A6
Pad configuration register 52 (DATA24) SIU_PCR52 16-bits Base + 0x00A8
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
