Freescale Semiconductor MPC5553 - Page 1135

MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-6 Freescale Semiconductor
Pad configuration register 53 (DATA25) SIU_PCR53 16-bits Base + 0x00AA
Pad configuration register 54 (DATA26) SIU_PCR54 16-bits Base + 0x00AC
Pad configuration register 55 (DATA27) SIU_PCR55 16-bits Base + 0x00AE
Pad configuration register 56 (DATA28) SIU_PCR56 16-bits Base + 0x00B0
Pad configuration register 57 (DATA29) SIU_PCR57 16-bits Base + 0x00B2
Pad configuration register 58 (DATA30) SIU_PCR58 16-bits Base + 0x00B4
Pad configuration register 59 (DATA31) SIU_PCR59 16-bits Base + 0x00B6
Pad configuration register 60 (TSIZ0) SIU_PCR60 16-bits Base + 0x00B8
Pad configuration register 61 (TSIZ1) SIU_PCR61 16-bits Base + 0x00BA
Pad configuration register 62 (RD_WR)
SIU_PCR62 16-bits Base + 0x00BC
Pad configuration register 63 (BDIP) SIU_PCR63 16-bits Base + 0x00BE
Pad configuration register 64 (WE0) SIU_PCR64 16-bits Base + 0x00C0
Pad configuration register 65 (WE1) SIU_PCR65 16-bits Base + 0x00C2
Pad configuration register 66 (WE2) SIU_PCR66 16-bits Base + 0x00C4
Pad configuration register 67 (WE3) SIU_PCR67 16-bits Base + 0x00C6
Pad configuration register 68 (OE) SIU_PCR68 16-bits Base + 0x00C8
Pad configuration register 69 (TS) SIU_PCR69 16-bits Base + 0x00CA
Pad configuration register 70 (TA) SIU_PCR70 16-bits Base + 0x00CC
Pad configuration register 71 (TEA) SIU_PCR71 16-bits Base + 0x00CE
Pad configuration register 72 (BR) SIU_PCR72 16-bits Base + 0x00D0
Pad configuration register 73 (BG) SIU_PCR73 16-bits Base + 0x00D2
Pad configuration register 74 (BB
) SIU_PCR74 16-bits Base + 0x00D4
Pad configuration register 75 (MDO4) SIU_PCR75 16-bits Base + 0x00D6
Pad configuration register 76 (MDO5) SIU_PCR76 16-bits Base + 0x00D8
Pad configuration register 77 (MDO6) SIU_PCR77 16-bits Base + 0x00DA
Pad configuration register 78 (MDO7) SIU_PCR78 16-bits Base + 0x00DC
Pad configuration register 79 (MDO8) SIU_PCR79 16-bits Base + 0x00DE
Pad configuration register 80 (MDO9) SIU_PCR80 16-bits Base + 0x00E0
Pad configuration register 81 (MDO10) SIU_PCR81 16-bits Base + 0x00E2
Pad configuration register 82 (MDO11) SIU_PCR82 16-bits Base + 0x00E4
Pad configuration register 83 (CNTXA) SIU_PCR83 16-bits Base + 0x00E6
Pad configuration register 84 (CNRXA) SIU_PCR84 16-bits Base + 0x00E8
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
