Pad configuration register 85 (CNTXB) SIU_PCR85 16-bits Base + 0x00EA
Pad configuration register 86 (CNRXB) SIU_PCR86 16-bits Base + 0x00EC
Pad configuration register 87 (CNTXC) SIU_PCR87 16-bits Base + 0x00EE
Pad configuration register 88 (CNRXC) SIU_PCR88 16-bits Base + 0x00F0
Pad configuration register 89 (TXDA) SIU_PCR89 16-bits Base + 0x00F2
Pad configuration register 90 (RXDA) SIU_PCR90 16-bits Base + 0x00F4
Pad configuration register 91 (TXDB) SIU_PCR91 16-bits Base + 0x00F6
Pad configuration register 92 (RXDB) SIU_PCR92 16-bits Base + 0x00F8
Pad configuration register 93 (SCKA) SIU_PCR93 16-bits Base + 0x00FA
Pad configuration register 94 (SINA) SIU_PCR94 16-bits Base + 0x00FC
Pad configuration register 95 (SOUTA) SIU_PCR95 16-bits Base + 0x00FE
Pad configuration register 96 (PCSA0) SIU_PCR96 16-bits Base + 0x0100
Pad configuration register 97 (PCSA1) SIU_PCR97 16-bits Base + 0x0102
Pad configuration register 98 (PCSA2) SIU_PCR98 16-bits Base + 0x0104
Pad configuration register 99 (PCSA3) SIU_PCR99 16-bits Base + 0x0106
Pad configuration register 100 (PCSA4) SIU_PCR100 16-bits Base + 0x0108
Pad configuration register 101 (PCSA6) SIU_PCR101 16-bits Base + 0x010A
Pad configuration register 102 (SCKB) SIU_PCR102 16-bits Base + 0x010C
Pad configuration register 103 (SINB) SIU_PCR103 16-bits Base + 0x010E
Pad configuration register 104 (SOUTB) SIU_PCR104 16-bits Base + 0x0110
Pad configuration register 105 (PCSB0) SIU_PCR105 16-bits Base + 0x0112
Pad configuration register 106 (PCSB1) SIU_PCR106 16-bits Base + 0x0114
Pad configuration register 107 (PCSB2) SIU_PCR107 16-bits Base + 0x0116
Pad configuration register 108 (PCSB3) SIU_PCR108 16-bits Base + 0x0118
Pad configuration register 109 (PCSB4) SIU_PCR109 16-bits Base + 0x011A
Pad configuration register 110 (PCSB5) SIU_PCR110 16-bits Base + 0x011C
Pad configuration register 111 (ETRIG0) SIU_PCR9111 16-bits Base + 0x011E
Pad configuration register 112 (ETRIG1) SIU_PCR112 16-bits Base + 0x0120
Pad configuration register 113 (TCRCLKA) SIU_PCR113 16-bits Base + 0x0122
Pad configuration register 114 (ETPUA0) SIU_PCR114 16-bits Base + 0x0124
Pad configuration register 115 (ETPUA1) SIU_PCR115 16-bits Base + 0x0126
Pad configuration register 116 (ETPUA2) SIU_PCR116 16-bits Base + 0x0128
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
