Pad configuration register 117 (ETPUA3) SIU_PCR117 16-bits Base + 0x012A
Pad configuration register 118 (ETPUA4) SIU_PCR118 16-bits Base + 0x012C
Pad configuration register 119 (ETPUA5) SIU_PCR119 16-bits Base + 0x012E
Pad configuration register 120 (ETPUA6) SIU_PCR120 16-bits Base + 0x0130
Pad configuration register 121 (ETPUA7) SIU_PCR121 16-bits Base + 0x0132
Pad configuration register 122 (ETPUA8) SIU_PCR122 16-bits Base + 0x0134
Pad configuration register 123 (ETPUA9) SIU_PCR123 16-bits Base + 0x0136
Pad configuration register 124 (ETPUA10) SIU_PCR124 16-bits Base + 0x0138
Pad configuration register 125 (ETPUA11) SIU_PCR125 16-bits Base + 0x013A
Pad configuration register 126 (ETPUA12) SIU_PCR126 16-bits Base + 0x013C
Pad configuration register 127 (ETPUA13) SIU_PCR127 16-bits Base + 0x013E
Pad configuration register 128 (ETPUA14) SIU_PCR128 16-bits Base + 0x0140
Pad configuration register 129 (ETPUA15) SIU_PCR129 16-bits Base + 0x0142
Pad configuration register 130 (ETPUA16) SIU_PCR130 16-bits Base + 0x0144
Pad configuration register 131 (ETPUA17) SIU_PCR131 16-bits Base + 0x0146
Pad configuration register 132 (ETPUA18) SIU_PCR132 16-bits Base + 0x0148
Pad configuration register 133 (ETPUA19) SIU_PCR133 16-bits Base + 0x014A
Pad configuration register 134 (ETPUA20) SIU_PCR134 16-bits Base + 0x014C
Pad configuration register 135 (ETPUA21) SIU_PCR135 16-bits Base + 0x014E
Pad configuration register 136 (ETPUA22) SIU_PCR136 16-bits Base + 0x0150
Pad configuration register 137 (ETPUA23) SIU_PCR137 16-bits Base + 0x0152
Pad configuration register 138 (ETPUA24) SIU_PCR138 16-bits Base + 0x0154
Pad configuration register 139 (ETPUA25) SIU_PCR139 16-bits Base + 0x0156
Pad configuration register 140 (ETPUA26) SIU_PCR140 16-bits Base + 0x0158
Pad configuration register 141 (ETPUA27) SIU_PCR141 16-bits Base + 0x015A
Pad configuration register 142 (ETPUA28) SIU_PCR142 16-bits Base + 0x015C
Pad configuration register 143 (ETPUA29) SIU_PCR143 16-bits Base + 0x015E
Pad configuration register 144 (ETPUA30) SIU_PCR144 16-bits Base + 0x0160
Pad configuration register 145 (ETPUA31) SIU_PCR145 16-bits Base + 0x0162
Pad configuration register 146 (TCRCLKB) SIU_PCR146 16-bits Base + 0x0164
Pad configuration register 147 (ETPUB0) SIU_PCR147 16-bits Base + 0x0166
Pad configuration register 148 (ETPUB1) SIU_PCR148 16-bits Base + 0x0168
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
