Pad configuration register 181 (EMIOS2) SIU_PCR181 16-bits Base + 0x01AA
Pad configuration register 182 (EMIOS3) SIU_PCR182 16-bits Base + 0x01AC
Pad configuration register 183 (EMIOS4) SIU_PCR183 16-bits Base + 0x01AE
Pad configuration register 184 (EMIOS5) SIU_PCR184 16-bits Base + 0x01B0
Pad configuration register 185 (EMIOS6) SIU_PCR185 16-bits Base + 0x01B2
Pad configuration register 186 (EMIOS7) SIU_PCR186 16-bits Base + 0x01B4
Pad configuration register 187 (EMIOS8) SIU_PCR187 16-bits Base + 0x01B6
Pad configuration register 188 (EMIOS9) SIU_PCR188 16-bits Base + 0x01B8
Pad configuration register 189 (EMIOS10) SIU_PCR189 16-bits Base + 0x01BA
Pad configuration register 190 (EMIOS11) SIU_PCR190 16-bits Base + 0x01BC
Pad configuration register 191 (EMIOS12) SIU_PCR191 16-bits Base + 0x01BE
Pad configuration register 192 (EMIOS13) SIU_PCR192 16-bits Base + 0x01C0
Pad configuration register 193 (EMIOS14) SIU_PCR193 16-bits Base + 0x01C2
Pad configuration register 194 (EMIOS15) SIU_PCR194 16-bits Base + 0x01C4
Pad configuration register 195 (EMIOS16) SIU_PCR195 16-bits Base + 0x01C6
Pad configuration register 196 (EMIOS17) SIU_PCR196 16-bits Base + 0x01C8
Pad configuration register 197 (EMIOS18) SIU_PCR197 16-bits Base + 0x01CA
Pad configuration register 198 (EMIOS19) SIU_PCR198 16-bits Base + 0x01CC
Pad configuration register 199 (EMIOS20) SIU_PCR199 16-bits Base + 0x01CE
Pad configuration register 200 (EMIOS21) SIU_PCR200 16-bits Base + 0x01D0
Pad configuration register 201 (EMIOS22) SIU_PCR201 16-bits Base + 0x01D2
Pad configuration register 202 (EMIOS23) SIU_PCR202 16-bits Base + 0x01D4
Pad configuration register 203 (GPIO203) SIU_PCR203 16-bits Base + 0x01D6
Pad configuration register 204 (GPIO204) SIU_PCR204 16-bits Base + 0x01D8
Pad configuration register 205 (GPIO205) SIU_PCR205 16-bits Base + 0x01DA
Pad configuration register 206 (GPIO206) SIU_PCR206 16-bits Base + 0x01DC
Pad configuration register 207 (GPIO207) SIU_PCR207 16-bits Base + 0x01DE
Pad configuration register 208 (PLLCFG0) SIU_PCR208 16-bits Base + 0x01E0
Pad configuration register 209 (PLLCFG1) SIU_PCR209 16-bits Base + 0x01E2
Pad configuration register 210 (RSTCFG) SIU_PCR210 16-bits Base + 0x01E4
Pad configuration register 211 (BOOTCFG0) SIU_PCR211 16-bits Base + 0x01E6
Pad configuration register 212 (BOOTCFG1) SIU_PCR212 16-bits Base + 0x01E8
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
