MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor A-11
Pad configuration register 213 (WKPCFG) SIU_PCR213 16-bits Base + 0x01EA
Pad configuration register 214 (ENGCLK) SIU_PCR214 16-bits Base + 0x01EC
Pad configuration register 215 (AN12) SIU_PCR215 16-bits Base + 0x01EE
Pad configuration register 216 (AN13) SIU_PCR216 16-bits Base + 0x01F0
Pad configuration register 217 (AN14) SIU_PCR217 16-bits Base + 0x01F2
Pad configuration register 218 (AN15) SIU_PCR218 16-bits Base + 0x01F4
Pad configuration register 219 (MCKO) SIU_PCR219 16-bits Base + 0x01F6
Pad configuration register 220 (MDO0) SIU_PCR220 16-bits Base + 0x01F8
Pad configuration register 221 (MDO1) SIU_PCR221 16-bits Base + 0x01FA
Pad configuration register 222 (MDO2) SIU_PCR222 16-bits Base + 0x01FC
Pad configuration register 223 (MDO3) SIU_PCR223 16-bits Base + 0x01FE
Pad configuration register 224 (MSEO0
) SIU_PCR224 16-bits Base + 0x0200
Pad configuration register 225 (MSEO1) SIU_PCR225 16-bits Base + 0x0202
Pad configuration register 226 (RDY) SIU_PCR226 16-bits Base + 0x0204
Pad configuration register 227 (EVTO) SIU_PCR227 16-bits Base + 0x0206
Pad configuration register 228 (TDO) SIU_PCR228 16-bits Base + 0x0208
Pad configuration register 229 (CLKOUT) SIU_PCR229 16-bits Base + 0x020A
Pad configuration register 230 (RSTOUT) SIU_PCR230 16-bits Base + 0x020C
Reserved — — Base + (0x020E-0x05FF)
GPIO pin data output register 0 SIU_GPDO0 8-bits Base + 0x0600
GPIO pin data output register 1 SIU_GPDO1 8-bits Base + 0x0601
GPIO pin data output register 2 SIU_GPDO2 8-bits Base + 0x0602
GPIO pin data output register 3 SIU_GPDO3 8-bits Base + 0x0603
GPIO pin data output register 4 SIU_GPDO4 8-bits Base + 0x0604
GPIO pin data output register 5 SIU_GPDO5 8-bits Base + 0x0605
GPIO pin data output register 6 SIU_GPDO6 8-bits Base + 0x0606
GPIO pin data output register 7 SIU_GPDO7 8-bits Base + 0x0607
GPIO pin data output register 8 SIU_GPDO8 8-bits Base + 0x0608
GPIO pin data output register 9 SIU_GPDO9 8-bits Base + 0x0609
GPIO pin data output register 10 SIU_GPDO10 8-bits Base + 0x060A
GPIO pin data output register 11 SIU_GPDO11 8-bits Base + 0x060B
GPIO pin data output register 12 SIU_GPDO12 8-bits Base + 0x060C
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
