MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-12 Freescale Semiconductor
GPIO pin data output register 13 SIU_GPDO13 8-bits Base + 0x060D
GPIO pin data output register 14 SIU_GPDO14 8-bits Base + 0x060E
GPIO pin data output register 15 SIU_GPDO15 8-bits Base + 0x060F
GPIO pin data output register 16 SIU_GPDO16 8-bits Base + 0x0610
GPIO pin data output register 17 SIU_GPDO17 8-bits Base + 0x0611
GPIO pin data output register 18 SIU_GPDO18 8-bits Base + 0x0612
GPIO pin data output register 19 SIU_GPDO19 8-bits Base + 0x0613
GPIO pin data output register 20 SIU_GPDO20 8-bits Base + 0x0614
GPIO pin data output register 21 SIU_GPDO21 8-bits Base + 0x0615
GPIO pin data output register 22 SIU_GPDO22 8-bits Base + 0x0616
GPIO pin data output register 23 SIU_GPDO23 8-bits Base + 0x0617
GPIO pin data output register 24 SIU_GPDO24 8-bits Base + 0x0618
GPIO pin data output register 25 SIU_GPDO25 8-bits Base + 0x0619
GPIO pin data output register 26 SIU_GPDO26 8-bits Base + 0x061A
GPIO pin data output register 27 SIU_GPDO27 8-bits Base + 0x061B
GPIO pin data output register 28 SIU_GPDO28 8-bits Base + 0x061C
GPIO pin data output register 29 SIU_GPDO29 8-bits Base + 0x061D
GPIO pin data output register 30 SIU_GPDO30 8-bits Base + 0x061E
GPIO pin data output register 31 SIU_GPDO31 8-bits Base + 0x061F
GPIO pin data output register 32 SIU_GPDO32 8-bits Base + 0x0620
GPIO pin data output register 33 SIU_GPDO33 8-bits Base + 0x0621
GPIO pin data output register 34 SIU_GPDO34 8-bits Base + 0x0622
GPIO pin data output register 35 SIU_GPDO35 8-bits Base + 0x0623
GPIO pin data output register 36 SIU_GPDO36 8-bits Base + 0x0624
GPIO pin data output register 37 SIU_GPDO37 8-bits Base + 0x0625
GPIO pin data output register 38 SIU_GPDO38 8-bits Base + 0x0626
GPIO pin data output register 39 SIU_GPDO39 8-bits Base + 0x0627
GPIO pin data output register 40 SIU_GPDO40 8-bits Base + 0x0628
GPIO pin data output register 41 SIU_GPDO41 8-bits Base + 0x0629
GPIO pin data output register 42 SIU_GPDO42 8-bits Base + 0x062A
GPIO pin data output register 43 SIU_GPDO43 8-bits Base + 0x062B
GPIO pin data output register 44 SIU_GPDO44 8-bits Base + 0x062C
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
To Next Page
