GPIO pin data input register 22 SIU_GPDI22 8-bits Base + 0x0816
GPIO pin data input register 23 SIU_GPDI23 8-bits Base + 0x0817
GPIO pin data input register 24 SIU_GPDI24 8-bits Base + 0x0818
GPIO pin data input register 25 SIU_GPDI25 8-bits Base + 0x0819
GPIO pin data input register 26 SIU_GPDI26 8-bits Base + 0x081A
GPIO pin data input register 27 SIU_GPDI27 8-bits Base + 0x081B
GPIO pin data input register 28 SIU_GPDI28 8-bits Base + 0x081C
GPIO pin data input register 29 SIU_GPDI29 8-bits Base + 0x081D
GPIO pin data input register 30 SIU_GPDI30 8-bits Base + 0x081E
GPIO pin data input register 31 SIU_GPDI31 8-bits Base + 0x081F
GPIO pin data input register 32 SIU_GPDI32 8-bits Base + 0x0820
GPIO pin data input register 33 SIU_GPDI33 8-bits Base + 0x0821
GPIO pin data input register 34 SIU_GPDI34 8-bits Base + 0x0822
GPIO pin data input register 35 SIU_GPDI35 8-bits Base + 0x0823
GPIO pin data input register 36 SIU_GPDI36 8-bits Base + 0x0824
GPIO pin data input register 37 SIU_GPDI37 8-bits Base + 0x0825
GPIO pin data input register 38 SIU_GPDI38 8-bits Base + 0x0826
GPIO pin data input register 39 SIU_GPDI39 8-bits Base + 0x0827
GPIO pin data input register 40 SIU_GPDI40 8-bits Base + 0x0828
GPIO pin data input register 41 SIU_GPDI41 8-bits Base + 0x0829
GPIO pin data input register 42 SIU_GPDI42 8-bits Base + 0x082A
GPIO pin data input register 43 SIU_GPDI43 8-bits Base + 0x082B
GPIO pin data input register 44 SIU_GPDI44 8-bits Base + 0x082C
GPIO pin data input register 45 SIU_GPDI45 8-bits Base + 0x082D
GPIO pin data input register 46 SIU_GPDI46 8-bits Base + 0x082E
GPIO pin data input register 47 SIU_GPDI47 8-bits Base + 0x082F
GPIO pin data input register 48 SIU_GPDI48 8-bits Base + 0x0830
GPIO pin data input register 49 SIU_GPDI49 8-bits Base + 0x0831
GPIO pin data input register 50 SIU_GPDI50 8-bits Base + 0x0832
GPIO pin data input register 51 SIU_GPDI51 8-bits Base + 0x0833
GPIO pin data input register 52 SIU_GPDI52 8-bits Base + 0x0834
GPIO pin data input register 53 SIU_GPDI53 8-bits Base + 0x0835
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
To Next Page
