MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-20 Freescale Semiconductor
GPIO pin data input register 54 SIU_GPDI54 8-bits Base + 0x0836
GPIO pin data input register 55 SIU_GPDI55 8-bits Base + 0x0837
GPIO pin data input register 56 SIU_GPDI56 8-bits Base + 0x0838
GPIO pin data input register 57 SIU_GPDI57 8-bits Base + 0x0839
GPIO pin data input register 58 SIU_GPDI58 8-bits Base + 0x083A
GPIO pin data input register 59 SIU_GPDI59 8-bits Base + 0x083B
GPIO pin data input register 60 SIU_GPDI60 8-bits Base + 0x083C
GPIO pin data input register 61 SIU_GPDI61 8-bits Base + 0x083D
GPIO pin data input register 62 SIU_GPDI62 8-bits Base + 0x083E
GPIO pin data input register 63 SIU_GPDI63 8-bits Base + 0x083F
GPIO pin data input register 64 SIU_GPDI64 8-bits Base + 0x0840
GPIO pin data input register 65 SIU_GPDI65 8-bits Base + 0x0841
GPIO pin data input register 66 SIU_GPDI66 8-bits Base + 0x0842
GPIO pin data input register 67 SIU_GPDI67 8-bits Base + 0x0843
GPIO pin data input register 68 SIU_GPDI68 8-bits Base + 0x0844
GPIO pin data input register 69 SIU_GPDI69 8-bits Base + 0x0845
GPIO pin data input register 70 SIU_GPDI70 8-bits Base + 0x0846
GPIO pin data input register 71 SIU_GPDI71 8-bits Base + 0x0847
GPIO pin data input register 72 SIU_GPDI72 8-bits Base + 0x0848
GPIO pin data input register 73 SIU_GPDI73 8-bits Base + 0x0849
GPIO pin data input register 74 SIU_GPDI74 8-bits Base + 0x084A
GPIO pin data input register 75 SIU_GPDI75 8-bits Base + 0x084B
GPIO pin data input register 76 SIU_GPDI76 8-bits Base + 0x084C
GPIO pin data input register 77 SIU_GPDI77 8-bits Base + 0x084D
GPIO pin data input register 78 SIU_GPDI78 8-bits Base + 0x084E
GPIO pin data input register 79 SIU_GPDI79 8-bits Base + 0x084F
GPIO pin data input register 80 SIU_GPDI80 8-bits Base + 0x0850
GPIO pin data input register 81 SIU_GPDI81 8-bits Base + 0x0851
GPIO pin data input register 82 SIU_GPDI82 8-bits Base + 0x0852
GPIO pin data input register 83 SIU_GPDI83 8-bits Base + 0x0853
GPIO pin data input register 84 SIU_GPDI84 8-bits Base + 0x0854
GPIO pin data input register 85 SIU_GPDI85 8-bits Base + 0x0855
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
To Next Page
