Freescale Semiconductor MPC5553 - Page 1159

MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-30 Freescale Semiconductor
eTPU A channel 20 host service request register ETPU_C20HSRR_A 32-bit Base + 0x0548
Reserved — — Base + (0x054C-0x054F)
eTPU A channel 21 configuration register ETPU_C21CR_A 32-bit Base + 0x0550
eTPU A channel 21 status and control register ETPU_C21SCR_A 32-bit Base + 0x0554
eTPU A channel 21 host service request register ETPU_C21HSRR_A 32-bit Base + 0x0558
Reserved — — Base + (0x055C-0x055F)
eTPU A channel 22 configuration register ETPU_C22CR_A 32-bit Base + 0x0560
eTPU A channel 22 status and control register ETPU_C22SCR_A 32-bit Base + 0x0564
eTPU A channel 22 host service request register ETPU_C22HSRR_A 32-bit Base + 0x0568
Reserved — — Base + (0x056C-0x056F)
eTPU A channel 23 configuration register ETPU_C23CR_A 32-bit Base + 0x0570
eTPU A channel 23 status and control register ETPU_C23CR_A 32-bit Base + 0x0574
eTPU A channel 23 host service request register ETPU_C23HSRR_A 32-bit Base + 0x0578
Reserved — — Base + (0x057C-0x057F)
eTPU A channel 24 configuration register ETPU_C24CR_A 32-bit Base + 0x0580
eTPU A channel 24 status and control register ETPU_C24SCR_A 32-bit Base + 0x0584
eTPU A channel 24 host service request register ETPU_C24HSRR_A 32-bit Base + 0x0588
Reserved — — Base + (0x058C-0x058F)
eTPU A channel 25 configuration register ETPU_C25CR_A 32-bit Base + 0x0590
eTPU A channel 25 status and control register ETPU_C25SCR_A 32-bit Base + 0x0594
eTPU A channel 25 host service request register ETPU_C25HSRR_A 32-bit Base + 0x0598
Reserved — — Base + (0x059C-0x059F)
eTPU A channel 26 configuration register ETPU_C26CR_A 32-bit Base + 0x05A0
eTPU A channel 26 status and control register ETPU_C26SCR_A 32-bit Base + 0x05A4
eTPU A channel 26 host service request register ETPU_C26HSRR_A 32-bit Base + 0x05A8
Reserved — — Base + (0x05AC-0x05AF)
eTPU A channel 27 configuration register ETPU_C27CR_A 32-bit Base + 0x05B0
eTPU A channel 27 status and control register ETPU_C27SCR_A 32-bit Base + 0x05B4
eTPU A channel 27 host service request register ETPU_C27HSRR_A 32-bit Base + 0x05B8
Reserved — — Base + (0x05BC-0x05BF)
eTPU A channel 28 configuration register ETPU_C28CR_A 32-bit Base + 0x05C0
eTPU A channel 28 status and control register ETPU_C28SCR_A 32-bit Base + 0x05C4
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
