6.3.1.12.6 MPC5553: Pad Configuration Register 44 (SIU_PCR44)
The SIU_PCR44 register controls the pin function, direction, and static electrical attributes of the
DATA[16]_FEC_TX_CLK_CAL_DATA[0]_GPIO[44] pin.
Figure 6-19. MPC5553: DATA[16]_FEC_TX_CLK_CAL_DATA[0]_GPIO[44]
Pad Configuration Register (SIU_PCR44)
Refer to Table 6-16 for bit field definitions.
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x0098 Access: Read [0:15] / Write[3:11, 14:15]
0123456789101112131415
R 000
PA
1
1
CAL_DATA[0] is for calibration only.
OBE
2
2
When configured as DATA[16], FEC_TX_CLK, or CAL_DATA[0], the OBE bit has no effect. When configured as GPO, set the
OBE bit to 1.
IBE
3
3
When configured as DATA[16], FEC_TX_CLK, CAL_DATA[0], or GPO, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
4
4
When configured as DATA[16] or CAL_DATA[0], clear the ODE bit to 0.
HYS
5
5
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
6
6
Refer to the EBI section for weak pullup settings when configured as DATA[16] or CAL_DATA[0].
WPS
6
W
RESET: 000000001100001 1
Table 6-18. PCR44 PA Field Definition
PA Field Pin Function
0b000 GPIO[44]
0b001 DATA[16]
0b010 FEC_TX_CLK
0b011 Reserved
0b100 CAL_DATA[0]
1
1
For calibration only.
