0 12 3 4 5 6 7 8 9101112131415
ROPCODE
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Address Base + 0x00EC
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R PAUSE_DUR
W
ResetUUUUUUUUUUUUUUU U
Address Base + 0x00EC
1
“U” signifies a bit that is uninitialized.
Figure 14-15. Opcode/Pause Duration Register (OPD)
Table 14-18. OPD Field Descriptions
Bits Name Description
0–15 OPCODE Opcode field used in PAUSE frames.
These bits are a constant, 0x0001.
16–31 PAUSE_DUR Pause duration field used in PAUSE frames.
