MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
19-30 Freescale Semiconductor
0 123456789101112131415
R CFS0_TSSI CFS1_TSSI CFS2_TSSI CFS3_TSSI CFS4_TSSI CFS5_TSSI 0 0 0 0
W
Reset0 000000000000000
Reg
Addr
Base + 0x00A8 (EQADC_CFSSR2)
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R ENI LCFTSSI TC_LCFTSSI
W
Reset0 111100000000000
Reg
Addr
Base + 0x00A8 (EQADC_CFSSR2)
Figure 19-13. eQADC CFIFO Status Snapshot Register 2 (EQADC_CFSSR2)
Table 19-16. EQADC_CFSSR2 Field Descriptions
Bits Name Description
0–11 CFSn_TSSI
[0:1]
CFIFO Status at Transfer through the eQADC SSI. Indicates the CFIFOn status at the time
a serial transmission through the eQADC SSI is initiated. CFSn_TSSI is a copy of the
corresponding CFSn in EQADC_CFSR (see Section 19.3.2.11) captured at the time a
serial transmission through the eQADC SSI is initiated.
12–15 — Reserved.
16 ENI External command buffer number Indicator. Indicates to which external command buffer
the last command was transmitted.
0 Last command was transferred to command buffer 2.
1 Last command was transferred to command buffer 3.
