MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 19-31
19.3.2.11 eQADC CFIFO Status Register (EQADC_CFSR)
The EQADC_CFSR contains the current CFIFO status. The EQADC_CFSRs are read only. Writing to the
EQADC_CFSR has no effect.
17–20 LCFTSSI
[0:3]
Last CFIFO to transfer commands through the eQADC SSI. Holds the CFIFO number of
last CFIFO to have initiated a command transfer to an external command buffer through
the eQADC SSI. LCFTSSI does not indicate the transmission of null messages. LCFTSSI
has the following values:
21–31 TC_LCFTSS
I[0:10]
Transfer counter for last CFIFO to transfer commands through eQADC SSI. Indicates the
number of commands which have been completely transferred from a particular CFIFO at
the time a command transfer from that CFIFO to an external command buffer is initiated.
TC_LCFTSSI is a copy of the corresponding TC_CFn in EQADC_CFTCRn (see Section
19.3.2.9) captured at the time a command transfer to an external command buffer is
initiated. This field has no meaning when LCFTSSI is 0b1111.
0123456789101112131415
RCFS0CFS1CFS2CFS3CFS4CFS50000
W
Reset0000000000000000
Reg Addr Base + 0x00AC
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R0000000000000000
W
Reset0000000000000000
Reg Addr Base + 0x00AC
Figure 19-14. eQADC CFIFO Status Register (EQADC_CFSR)
Table 19-16. EQADC_CFSSR2 Field Descriptions (Continued)
Bits Name Description
LCFTSSI[0:3] LCFTSSI Meaning
0b0000 Last command was transferred from CFIFO0
0b0001 Last command was transferred from CFIFO1
0b0010 Last command was transferred from CFIFO2
0b0011 Last command was transferred from CFIFO3
0b0100 Last command was transferred from CFIFO4
0b0101 Last command was transferred from CFIFO5
0b0110 –
0b1110
Reserved
0b1111 No command was transferred to an external command buffer
