Freescale Semiconductor MPC5553 - Page 80

MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 2-33
V
DDE12
External I/O Supply Input –
Calibration
P I 1.8–3.3 V
V
DDE
N.A. V
DDE12
K7, N8,
R11:13,
R17:18,
R21,
T11:12,
T15, T18,
U2, U11,
U15:16,
V15:17,
V22, AA13,
AA16,
AB18,
AB21, AE2,
AG4, AG12
V
DDEH1
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH1
G11, J7 E3, F4
V
DDEH4
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH4
AD20 AC20
V
DDEH6
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH6
V26 AA23, J23
V
DDEH8
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH8
C21 D22
V
DDEH9
34
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH9
H14 J23
V
DDEH10
External I/O High Supply Input P I
3.3
–5.0 V
V
DDEH
N.A. V
DDEH10
K24 D14
V
DD33
35
3.3v I/O SUPPLY Input P I 3.3 V V
DD33
N.A. V
DD33
B26, D2,
W5, AE27,
AF9
C1, U4,
AD9,
A25, AD26
Table 2-2. MPC5554 Signal Properties (Continued)
Signal Names
1
Signal Functions
2
P/
A/
G
I/O
Type
Voltage
3
Pad
Type
4
Status Pin Labels / Package
During
Reset
5
After
Reset
6
496
7
416
