MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 20-17
20-23 ASC
[0:3]
After SCK delay scaler. Selects the scaler value for the After SCK delay. This field is
only used in master mode. The after SCK delay is the delay between the last edge of
SCK and the negation of PCS. The table below lists the scaler values.
The after SCK delay is a multiple of the system clock period, and it is computed
according to the following equation:
Note: See Section 20.4.6.3, “After SCK Delay (tASC),” for more details.
Table 20-5. DSPIx_CTARn Field Description (Continued)
Bits Name Description
ASC
After SCK Delay
Scaler Value
ASC
After SCK Delay
Scaler Value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
t
ASC
1
t
SYS
-----------
PASC Prescaler value ASC Scaler value=
