12 Disturbance Analyzer Measurement
Remote Command Results for Disturbance Analyzer
Command n Return Value
INITiate:DANalyzer n/a n/a
CONFigure? n/a Name of current measurement: "DANalyzer"
CONFigure:DANalyzer n/a n/a (selects DAN measurement in Meas Preset state)
CONFigure:DANalyzer:NDEFault n/a n/a (selects DAN measurement without affecting settings)
FETCh:DANalyzer[n]?
MEASure:DANalyzer[n]?
READ:DANalyzer[n]?
not
specified
or n=1
Returns comma separated list containing detailed information in
the following format:
• Time Remaining
• Counted Clicks
• Click Rate
• Lq
• Clicks > Lq
• Counted Continuous Disturbance
• Total Time of Continuous Disturbance
2 Returns comma separated list containing detailed information in
the following format:
• Number of disturbance in the following list (integer)
[Repeat the following for each disturbance]
• Disturbance#
• Duration of Disturbance
• Peak Amplitude
• Quasi Peak Amplitude
3 Returns comma separated list containing detailed information in
the following format:
• Frequency
• Measurement Duration
• Click Rate
• Click < 10ms
• Click <= 10ms
• Click ( >10ms – 20ms )
• Click > 20ms
• Click > Lq
• Click > Lq ( Percent )
• L
• Lq
• Counted Continuous Disturbance
• Total Time of Continuous Disturbance
• Exception Rule Used : 600ms Combination
• Exception Rule Used : Separation of Click < 200ms
EMI Receiver Mode Reference 1029
