Keysight PXA X Series User Manual

4 Input/Output Functions
Input/Output
BTS
Sets an external attenuation value for BTS (Base Transceiver Station) tests.
Key Path
Input/Output, External Gain
Remote Command
[:SENSe]:CORRection:BTS[:RF]:GAIN <rel_ampl>
[:SENSe]:CORRection:BTS[:RF]:GAIN?
Example CORR:BTS:GAIN 10 sets the Ext Gain value to 10dB
CORR:BTS:GAIN –10 sets the Ext Gain value to –10dB (that is, a loss of 10dB.)
Notes Does not auto return.
Dependencies The reference level limits are determined in part by the External Gain, Max Mixer Level, RF Atten
This key is grayed out in modes that do not support BTS.
Preset This is unaffected by a Preset but is set to 0dB on a "Restore Input/Output Defaults" or "Restore
System Defaults->All"
State Saved Saved in instrument state.
Min –100dB
Max 100dB
Readback BTS, <Ext Gain value>dB
Initial S/W Revision Prior to A.02.00
Remote Command
[:SENSe]:CORRection:BTS[:RF]:LOSS <rel_ampl>
[:SENSe]:CORRection:BTS[:RF]:LOSS?
Example CORR:BTS:LOSS 10 sets the Ext Gain value to –10dB, and subsequently querying :LOSS will give 10
dB
CORR:BTS:LOSS –10 sets the Ext Gain value to 10dB, and subsequently querying :LOSS will give –
10 dB
Notes A positive value of <rel_ampl> in the above command means a loss and a negative value indicates a
gain.
Anytime :LOSS is set it sets :GAIN to the negative value of the parameter sent.
Anytime :LOSS is queried it gives the negative of :GAIN
Preset This is unaffected by a Preset but is set to 0dB on a "Restore Input/Output Defaults" or "Restore
System Defaults->All"
Min 100dB
Max –100dB
Initial S/W Revision Prior to A.02.00
EMI Receiver Mode Reference 181
