Keysight PXA X Series User Manual

7 Trigger Functions
Trigger
TD-SCDMA,
1xEVDO, LTE,
LTETDD, CMMB,
ISDB-T, MSR
source. When the trigger source changes to
RFBurst, External1 or External2, the gate state
is set to on, and the gate source is set
identically with the trigger source. When the
trigger source changes to IMMediate, VIDeo,
LINE, FRAMe or IF, the gate state is set to off.
CCDF SA, WCDMA, C2K,
WIMAXOFDMA,
TD-SCDMA,
1xEV-DO, DVB-
T/H, DTMB, LTE,
LTETDD, CMMB,
ISDB-T, Digital
Cable TV, MSR
WIMAXOFDMA:
RFBurst
LTETDD:
BTS: External 1
MS: Periodic
Timer
TD-SCDMA and
1xEV-DO:
BTS: External 1
MS: RFBurst
SA, WCDMA, C2K,
LTE, CMMB, ISDB-
T, DVB-T/H,
DTMB, Digital
Cable TV, MSR:
IMMediate
TD-SCDMA
and 1xEV-DO:
BTS: External
1
MS: IQMag
LTETDD:
BTS: External
1
MS: Periodic
Timer
Others: IMM
For TD-SCDMA:
Trigger source is coupled with radio device.
When radio device changes to BTS, trigger
source will be changed to EXTernal1. When
radio device changes to MS, trigger source will
be set as RFBurst for RF or IQ Mag for BBIQ.
When TriggerSource is RFBurst or IQ Mag,
Measure Interval is grayed out.
ACP SA, WCDMA, C2K,
WIMAX OFDMA,
TD-SCDMA,
1xEVDO, DVB-
T/H, DTMB, LTE,
LTETDD, CMMB,
ISDB-T, Digital
Cable TV, MSR
IMM IQ not
supported
Tx Power SA, GSM, TD-
SCDMA
SA, GSM: RFBurst
TD-SCDMA:
EXTernal
IMM TD-SCDMA doesn't support the Line and
Periodic Timer parameters.
When the mode is TD-SCDMA, if the Radio
Device is switched to BTS, the value will be
changed to External 1 and if the Radio device is
switched to MS, the value will be changed to
RFBurst
SPUR SA, WCDMA, C2K,
WIMAX OFDMA,
TD-SCDMA,1xEV-
DO, DVB-T/H,
LTE, LTETDD,
MSR
IMM IQ not
supported
SEM SA, WCDMA, C2K,
WIMAX OFDMA,
TD-SCDMA,
1xEVDO, DVB-
1xEVDO(BTS):
EXTernal1
All others:
IMMediate
IQ not
supported
360 EMI Receiver Mode Reference
