8 Frequency Scan Measurement

Save

• Int Preamp Band

• Int Preamp State

• Log Percentage

• Meas Time

• Meas Time Mode

• Point/RBW

• RBW

• RBW Mode

• RF Input

• Scan Points

• Scan Points Mode

• Scan Time

• Scan Time Mode

• Start Freq

• State

• Step Auto Mode

• Step Size

• Step Size Mode

• Step Time Control

• Stop Freq

Here is an example of scan table file:

ScanTable

EMI:FSCAN

A.12.08,N9030A

526 ALV B25 B40 CR3 CRP DP2 EA3 EMC EP1 FSA LFE LNP MPB NFE NUL P26 PFR RTL YAV ,01

Step Time Control,Step Size & Dwell Time

State,OFF,OFF,OFF,OFF,ON,OFF,OFF,OFF,OFF,OFF

Start

Freq,9000,150000,30000000,300000000,30000000,1000000000,1000000000,1000100000,1000200000,1000300000

Stop

Freq,150000,30000000,300000000,1000000000,1000000000,18000000000,1000100000,1000200000,1000300000,1

000400000

RBW,200,9000,120000,120000,120000,1000000,1000000,1000000,1000000,1000000

RBW Mode,AUTO,AUTO,AUTO,AUTO,AUTO,AUTO,AUTO,AUTO,AUTO,AUTO

556 EMI Receiver Mode Reference
