214733 181 Revision A
Windrowers with center-link self-alignment kit only:
Figure 4.155: Center-Link
10. Release the center-link latch (A) before returning to
the cab.
Figure 4.156: Safety Props
11. Disengage safety prop by turning lever (A) downwards until
lever locks into the vertical position.
12. Repeat for the opposite side.
CAUTION
Check to be sure all bystanders have cleared the area.
13. Start engine and remove header float when prompted by the Harvest Performance Tracker (HPT).
NOTE:
If not prompted by the HPT to remove float, remove float manually.
14. Lower the header to the ground.
OPERATION
